Self-Contained Letters are ideal for large channel letter projects generally between 3′ and 10′. Each letter contains its own transformers and is pre-assembled for easy installation.
Faces : 3/16” acrylic precision-cut faces or polycarbonate precision-CNC cut faces. Polycarbonate is typically used for large sign faces
Trim : 3/4″ or 1″. Custom fabricated aluminum trim is also available and is standard for large logos. Aluminum trim can be painted to match most color options.
Backs : .063, .080, .090, or .125 aluminum; mounting and electrical holes are CNC cut into the back.
Returns : .063 return standard 5″ to 8″ depth. Custom depths range from 9″ to 12″. Welded or Preformed construction. Preformed is only available in 5″ depth. The gauge of material is determined by the dimension of the project.
Mounting : Remote-Self-Contained and Square Tube Grid. Custom mounting options available at request.
Lighting : We offer a standard stock of Principal LED modules to fit all product applications which include a 10-year parts, 5-year labor warranty. UL or non-UL listed.
Self Contained LED Illuminated Channel Letters are assembled with the power supplies mounted to the inside back of the letters. The lightweight design of an LED module reduces damages during transit. These letters can contain a large amount of lighting. LED signage is a great way to reduce long term cost. Self contained letters are wired and ready for installation.
Self-Contained Letters are ideal for large channel letter projects generally between 3′ and 10′. Each letter contains its own transformers and is pre-assembled for easy installation.
Faces : 3/16” acrylic precision-cut faces or polycarbonate precision-CNC cut faces. Polycarbonate is typically used for large sign faces
Trim : 3/4″ or 1″. Custom fabricated aluminum trim is also available and is standard for large logos. Aluminum trim can be painted to match most color options.
Backs : .063, .080, .090, or .125 aluminum; mounting and electrical holes are CNC cut into the back.
Returns : .063 return standard 5″ to 8″ depth. Custom depths range from 9″ to 12″. Welded or Preformed construction. Preformed is only available in 5″ depth. The gauge of material is determined by the dimension of the project.
Mounting : Remote-Self-Contained and Square Tube Grid. Custom mounting options available at request.
Lighting : We offer a standard stock of Principal LED modules to fit all product applications which include a 10-year parts, 5-year labor warranty. UL or non-UL listed.
Self Contained LED Illuminated Channel Letters are assembled with the power supplies mounted to the inside back of the letters. The lightweight design of an LED module reduces damages during transit. These letters can contain a large amount of lighting. LED signage is a great way to reduce long term cost. Self contained letters are wired and ready for installation.
Check out our Sign Industry Resources for Sign Professionals.
There are a collection of informative videos on our video page in sign installations.
Got any questions about us? Find the answers on our FAQs page.
There are many different sign galleries in our Sign Products section.
GALLERY
Alum. Face: cabinet – Painted Black
Face: Letters – 7328 White plex UV printed to match PMS 2613C Purple, Black & White
Trim: Letters – Trimless with lit edge
Return: cabinet – Black; Letters – Black
LEDs: White
Face: Purple with 2856 Vinyl on White plex
Return: 2” Black
LEDs: Purple
Face: Cabinet – Painted Black with 2100-002 White; Swoosh – 7328 White with 2500-33 Red
Trim: Swoosh – Red
Return: Swoosh – Welded Painted to match Red trim; Cabinet – Welded painted Black
Wowee Letters: Sign Fab – Letters mounted to face Painted to match Red trim.
LEDs: White
Face: 2793 Red
Return: 2” Black
LEDs: Red
Face: White, Red and Blue
Trim: Red and Blue
Return: White, Red and Blue
LEDs: White
Face: UV Print on Foamcore
Face: Sir Speedy – Routed Painted Brushed Aluminum with 3/16” 7328 White push thru with UV print
Return: 3” Painted Brushed Aluminum
LEDs: White
Face: UV print to match artwork, routed out backed w/ 7328 White
Return: 3” Painted Black
LEDs: White
Face: Painted MP 41342SP Brushed Aluminum routed out backed w/ 7328 White (BioTouch – UV print to match Pantone 669C Purple) (Logo – UV print to match gradient Pantone 669C
Purple and Pantone 2286C Green)
Return: 3” Painted MP 41342SP Brushed Aluminum
LEDs: White
Face: Maxi – White polycarbonate w/ Flatbed Uv print to match Pms 3242C Blue leaving Black outline; Laine’s – White polycarbonate w/ Flatbed UV print to match Pms 238C Pink leaving Black outline; Capsule – 7328 White plex w/ Arlon 2500-22 Black vinyl applied leaving White copy as per artwork.
Trim: 1” Black
Return: 3” pre-finished Black
LEDs: White
Face: 7328 white plex
Trim: 1” White
Return: 4” pre-finished White
LEDs: RGB
Raceway: Painted to match PMS 7699C Blue
Face: Routed aluminum painted Black w/ 3/4” 7328 White acrylic with 1/2” push thru; “n” – high concentration ink digital print applied as per artwork; “COMMUNITIES” – high concentration ink digital print applied to aluminum face as per artwork.
Return: 16” welded painted Black
LEDs: White
Face: Top Cabinet – White poly w/ 3M 3630-74 Kumquat Orange & Arlon 2500-22 Black vinyl applied as per artwork
Aluminum Faces: Pole Skirt – .090 aluminum painted Satin Black
Trim: 1” x 1” aluminum trim painted satin Black
Return: Top Cabinet – 19” welded painted satin Black
Return: Pole Skirt – 22” welded painted satin Black
LEDs: White
Alum. Face: .100 aluminum painted White; 1 revel painted PMS 286C Blue; 1 revel painted PMS 404C Gray; Bottom painted to match PMS Cool Gray 11C
Plex Face: Eigen – 3/4” 7328 white plex w/ 1/2” push through w/ high concentration in digital print to match PMS404C Gray applied as per artwork; 1030 – 3/4” 7328 White plex w/ 1/2” push through; X – 3/4” 7328 White plex w/ 1/2” push through w/ high concentration ink digital print to match PMS 286C Blue applied as per artwork; ® – Dacoit High concentration ink digital print applied to match PMS 404C Gray.
Trim: None
Backs: None
Return: 16” painted white; 1 revel painted PMS 286C Blue; 1 revel painted PMS 404C Gray; Bottom painted to match PMS Cool Gray 11C
LEDs: White
Face: Letters – 7328 white plex / logo – 7328 white plex w/ digital print as per artwork (FB).
Trim: 1” Brown
Backs: clear lexan w/ Arlon 2500-36 Dark Blue vinyl applied to create blue halo and Arlon 2500-20 White applied for face lighting.
Return: 4” pre-finished Brown
LEDs: White
Face: Polycarbonate White w/ High Concentration ink digital print to match artwork.
Trim: 1” Black
Return: 3” pre-finished Black
LEDs: White
Face: 7328 White plex w/ (FB) flat bed UV print printed to match black leaving white copy as per artwork.
Trim: 1” Black
Return: 3” pre-finished Black
LEDs: White
Raceway: Painted PMS 4755 Beige
Face: 7328 white plex w/ flatbed UV print to match artwork.
Trim: 1” Black
Return: 3” pre-finished Black
LEDs: White
Raceway: Painted Black
Face: 2447 White plex w/ Arlon 2500-25 Sunflower Yellow vinyl applied as per artwork.
Trim: 3/4” Black
Return: 3” pre-finished Black
LEDs: White
Raceway: painted to match PMS 4239C Tan
Face: Letters – 7328 white plex; Logo – 7328 white plex with high concentration ink digital print applied as per artwork.
Trim: 3/4” Black
Return: 3” pre-finished Black
LEDs: White
Raceway: Painted SW 7074 Software
Face: 7328 White plex
Trim: Image – 1” Black; Studio – 3/4” Black
Return: 5” pre-finished Black
LEDs: White
Face: 2793 Red plex
Trim: 3/4” Black
Return: 3” pre-finished Black
LEDs: Red
Raceway: Painted to match SW 7074 Software
Face: Letters – 7328 white plex / Logo – 7328 white plex w/ Arlon 2500-22 Black vinyl applied leaving white copy as per artwork.
Trim: 3/4” Black
Return: 3” pre-finished Black
LEDs: White
Backer: flat cut ACM painted SW Black
Face: 7328 white plex w/ flatbed UV print to match PMS 2268C Green
Trim: 3/4” White
Return: 3” pre-finished painted to match digital print of PMS 2268C Green
LEDs: White
Raceway: Painted to match SW 7591 Red Barn
Face: 7328 white plex w/ Arlon 2500-22 Black & Arlon 2500-525 Yellow vinyl applied as per artwork.
Trim: 1” Black
Return: 3” pre-finished Black
LEDs: White
Face: 2447 white plex w/ high concentration ink digital print applied as per artwork.
Trim: 1” Black
Return: 3” pre-finished Black
LEDs: White
Face: 7328 white plex w/ high concentration ink digital print applied as per artwork.
Trim: 3/4” Black
Return: 3” pre-finished Black
LEDs: White
Raceway: Painted SW 7074 Software
Flat cut-outs: .090 flat cut aluminum w/ digital print applied to opaque material to match CMYK Yellow 0.50.100.0, Black, and White as per artwork (DP) ***Backs painted black***.
Mounting Options: Mounted to 1” square tube rails painted black.
Flat cut-outs: .090 flat cut aluminum w/ digital print to match PMS 293C Royal Blue, PMS 187C Cardinal Red & White applied to opaque material as per artwork (DP) ***Backs painted black***.
Mounting Options: Mounted to 1” square tube rails painted black.
Flat cut-outs: .090 flat cut aluminum w/ digital print to match PMS 187C Cardinal Red, PMS 443C Silver Gray. Black & White as per artwork (HC) ***Backs painted black***.
Mounting Options: Mounted to 1” square tube rails painted black.
Face: 2447 White plex w/ high concentration ink digital print to match PMS 375C Green & PMS 293C Blue leaving white outline as per artwork.
Trim: 3/4” White
Return: 4” pre-finished White
LEDs: White
Face: 7328 white plex w/ Arlon 2500-2940 Blue and Arlon 2500-051 Silver Grey Applied leaving white copy as per artwork.
Trim: 1” Black
Return: 5” pre-finished Black
LEDs: White
Raceway: Painted SW 6084 Modest White
Flat cut-outs: .090 flat cut aluminum w/ digital print to match black applied to opaque material as per artwork ***Backs painted black***.
Mounting Options: Mounted to 1” square tube rails painted black.
Flat cut-outs: .090 flat cut aluminum w/ digital print to match PMS 7680C Purple, Black, and CMYK 0.0.0.25 Gray applied to opaque material as per artwork ***Backs painted black***.
Mounting Options: Mounted to 1” square tube rails painted black.
Flat cut-outs: .090 flat cut aluminum w/ digital print to match PMS 293C Royal Blue, White, Black, and Gray [CMYK 32.25.25.0] as per artwork applied to opaque material ***Backs painted black***.
Mounting Options: Mounted to 1” square tube rails painted black.
Flat cut-outs: .090 flat cut aluminum w/ High concentration ink digital print to match PMS 2965C Navy, PMS 136C Yellow, and White applied to opaque material as per artwork (DP) ***Backs painted black***.
Mounting Options: Mounted to 1” square tube rails painted black.
Face: Letters – 2793 Red plex; Logo – White polycarbonate with Flatbed UV print to match artwork.
Trim: Letters – 3/4” Black; Logo – 1” Black.
Return: 3” pre-finished Black
LEDs: Logo – White; Letters – Red
Aluminum Face: .100 aluminum painted PMS 541C Blue with digital print applied to opaque material as per artwork with Arlon 2500-22 Black vinyl applied around routed lettering as per artwork with routed out with 3/4” 7328 white acrylic with 1/2” push thru with (®) digital print applied to match PMS 541C Dark Blue applied as per artwork.
Back: Clear lexan
Return: 6” welded painted PMS 541C Blue
LEDs: Front – White; Halo – Blue
Face: White polycarbonate w/ Flatbed UV print to match red trimcap as per artwork
Trim: 1” Red
Backs: Clear polycarbonate w/ partitions
Return: 4” pre-finished White
LEDs: White
Face: 2447 white plex w/ digital print applied to all as per artwork (high concentration ink).
Trim: 1” White
Return: 4” pre-finished White
LEDs: White
Face: White polycarbonate w/ flatbed UV print applied as per artwork.
Trim: 1” x 1” aluminum trim painted SW Black.
Return: 4” welded painted SW Black
LEDs: White
Face: White with multiple colors of vinyl
Trim: 1” Brown
Return: 4” pre-finished Brown
LEDs: White
Face: White polycarbonate w/ Flatbed UV print to match artwork.
Trim: 1” Black
Return: 5” pre-finished Black
LEDs: White
Face: White polycarbonate w/ flatbed UV print to match Artwork
Trim: 1” x 1” aluminum trim painted black
Return: 3” welded painted black
LEDs: White
Flat cut-outs: .090 flat cut aluminum w/ high concentration ink digital print to match PMS 293C Royal Blue applied to opaque material as per artwork (DP) ***Backs painted black***.
Mounting Options: Mounted to 1” square tube rails painted black.
Flat cut-outs: 090 flat cut aluminum w/ digital print to match PMS 2965C Navy, CMYK: 0, 24, 94, 0 Yellow and white as per artwork applied to opaque material as per artwork (DP) ***Backs painted black***.
Mounting Options: Mounted to 1” square tube rails painted black.
Face: 7328 white Plex w/ flat bed uv print to match CMYK 0-0-0-5 gray, CMYK 53-44-44-9 dark gray, CMYK
22-4-1-0 light blue, CMYK 73-33-6-0 blue, and CMYK 2-47-78-0 orange as per artwork
Trim: 1” black
Return: 6” welded painted black
LEDs: White
Face: White polycarbonate w/ Flatbed UV print to match artwork
Trim: 1” black
Return: 4” pre-finished black
LEDs: White
Face: Logo – 7328 white plex w/ flat bed uv print as per artwork.
Trim: 1” black
Return: 4” pre-finished black
LEDs: White
Face: 2447 White with digital print applied as per artwork (gold to match Arlon 2500-131 gold metallic vinyl)
Trim: Black
Return: Prefinished black
Return: 4” welded painted Black
LEDs: White
Flat cut-outs: 125 flat cut aluminum w/ digital print applied to match PMS 187C Red, PMS 293C Blue, PMS 443C Gray & White as per artwork. (Backs painted black).
Mounting Options: Mounted to 1” square tube rails painted black.
Alum. Face: 100 aluminum painted PMS 7506C Beige & PMS 462C Brown as per artwork w/ routed face w/ 3/4” 7328 white acrylic w/ 1/2” push (The Prickley Pear) w/ digital print to match PMS 3282C Teal (HC) / (Catctus) w/ digital print to match PMS 375C Green, PMS 462C Brown & PMS 785C Pink as per artwork (HC).
Return: 8” welded painted PMS 462C Brown.
Illumination: White QwikMod LED’s.
Face: Letters – 7328 White; Cabinet – 7328 White with 2500-3238 European Blue vinyl.
Trim: Letters – 1″ White.
Alum. Trim: Cabinet – 4.5″ x 4.5″ painted White.
Return: Letters – 4″ prefinished White; Cabinet – 18″ welded painted White.
Illumination: White QwikMod LED’s.
Face: 7328 White with digital print
Trim: 2”x2″ Aluminum trim painted black.
Return: 6” welded painted black
LEDs: White
Mounting Options: Remote
Face: Letters – 7328 White with multiple colors of vinyl
Trim: Letters – 3/4″ Black; Logo – 1″ Black
Return: Letters – pre-finished Black
Return: Logo – painted Black
LEDs: White
Mounting Options: Raceway
Face: Clear da w/ digital print as per artwork.
Trim: 1” black.
Return: 4” pre-finished black
LEDs: White
Mounting Options: Remote mounted
Face: Clear da w/ digital print as per artwork.
Trim: 1” black.
Return: 4” pre-finished black
LEDs: White
Mounting Options: Raceway mounted
Face: Letters – 7328 White; Logo – 2447 White with digital print
Trim: Letters – 3/4″ Black; Logo – 1″ Black
Return: Letters – 4” pre-finished Black
Return: Logo – 8.5” welded painted Black
LEDs: White
Mounting Options: Raceway painted PMS 730C Brown
Alum. Faces: Reverse Channel painted Satin; CARDINAL CONTRACTORS – Black
Face: Logo – 2447 White with digital print
Trim: Logo – Black
Return: CARDINAL CONTRACTORS – Painted Satin Black; Logo – Black
LEDs: White
Mounting Options: Remote
Face: Letters – 7328 White; Logo – 7328 White with 2500-22 Black
Trim: Black
Return: Black
LED: White
Mounting Options: Raceway – Painted PMS 1655C orange
Faces: Letters – 2447 White with 5590-122 Black perf.; Logo – digital print to match PMS 2613C Purple, PMS 254C Medium Purple, PMS 234C Red, PMS 233C Medium Red & PMS 179C Orange
Face: Cabinet – Painted Satin SW 7006 Extra White
Trim: Letters – Black
LED: White
Mounting Options: Cabinet
Faces: Top Section – White with digital print to match PMS 4655 C Beige, PMS 293 C Blue and White
Alum. Face: Bottom Section – Painted Satin PMS 293C Blue
Alum. Trim: Top Section – Painted Satin White
Backs: Top – Painted White; Bottom – Painted PMS 293 C Blue
Return: Top – Painted Satin White – Painted Satin PMS 293C Blue
Mounting Options: Cabinet
Faces: 2447 White with digital print to match PMS 239C Light Pink, PMS 241C Dark Pink PMS 10C Cool Gray & White
Return: Black
LEDs: White
Backs: Clear with 2500-133 Raspberry and 2500-20 White
Mounting Options: Remote
Alum. Faces: Reverse Channel painted RAL 7021 Black Grey
Return: Painted RAL 7021 Black Grey
LEDs: White
Mounting Options: Remote
Alum. Faces: Letters & Logo – Painted Satin White; Cabinet – Painted Suede PMS 11C Cool Gray
Return: Letters & Logo – Painted Satin White; Cabinet – Painted Suede PMS 11C Cool Gray
LEDs: White
Mounting Options: Self-Contained
Faces: Letters – 2447 white plex w/ digital print as per artwork (flatbed)
Trim: 1” Black
Return: 4” pre-finished black
LEDs: Orange
Mounting Options: Remote
Faces: 7328 white plex
Trim: 1” white
Return: 4” pre-finished black
LEDs: Front – White; Halo Lighting – Green
Mounting Options: Raceway – painted Black
Plex Faces: 2447 white plex w/ digital print overlay applied to match SW 7732 Lemon Grass (double layer).
Trim: 1” painted to match SW 7055 Enduring Bronze
Return: Aluminum
Return: Brothers – 4” prefinished painted to match SW 7055 Enduring Bronze
LEDs: White
Mounting Options: Raceway – painted SW 7591 Red Barn
Face: Clear da w/ digital print as per artwork.
Trim: 1” black.
Return: 4” pre-finished black
LEDs: White
Mounting Options: Raceway – painted PMS 2330C light Beige
Face: Clear polycarbonate w/ digital print applied as per artwork (flatbed).
Trim: 1” x 1” aluminum trim painted Satin Black
Return: 6” welded painted Satin Black
LEDs: White
Mounting Options: Remote
Face: Letters – 7328 white plex w/ Arlon 2500-22 Black & Arlon 2500-33 Red vinyl applied as per artwork / Logo – 2447 white plex w/ digital print as per artwork (high concentration).
Trim: 1” black
Return: 4” pre-finished black
LEDs: White
Mounting Options: Raceway – painted SW 7026 Griffin.
Face: Cabinet – routed aluminum painted **Three colors** Satin White, Matthews MP 24069 Fire Red & Satin Black as per artwork w/ 3/4” 7328 white acrylic with 1/2” push thru w/ arlon 2500-22 black vinyl applied as per artwork.
Face: LEE’S – 7328 white plex w/ arlon 2500-33 red vinyl overlay applied / Country – 2447 white plex w/ arlon 5590-122 black perforated vinyl overlay applied / RV – 7328 white plex w/ arlon 2500-33 red vinyl applied leaving a white outline.
Trim: LEE’s Country RV – 3/4” black
Return: Cabinet – 18” painted Matthews MP 24069 Fire Red
Return: LEE’s Country RV – 4” prefinished black
LEDs: White
Mounting Options: Self-Contained
Face: 7328 white polycarb w/ Arlon 2500-33 Red & Arlon 2500-3238 European Blue vinyl applied as per artwork.
Trim: 1.5” x 1.5” aluminum trim painted SW 6811 Honorable Blue.
Return: 6” welded painted SW 6811 Honorable Blue
LEDs: White
Mounting Options: Self-Contained
Face: Letters – 7328 white plex / Logo – 2447 white plex w/ Arlon 2500-22 Black vinyl and Arlon 2500-131 Gold Metallic vinyl applied as per artwork / Cabinet – Arlon 2500-131 Gold Metallic vinyl applied as per artwork
Trim: Letters – 3/4” black / Logo – 1” black
Return: Letters – 4” pre-finished black / Interiors white
LEDs: : Logo, Letters & Cabinet – White
Mounting Options: Self-Contained – painted Matthews Brushed Aluminum & Satin Black as per artwork
Face: 2793 Red Plex
Trim: 1” black
Return: 4” pre-finished black
LED: Red
Mounting Options: Raceway
Face: 2447 white plex / paddio – Arlon 2500-36 dark blue vinyl overlay / logos – Arlon 2500-83 regal red vinyl overlay.
Trim: 1” white
Return: 4” pre-finished white
LED: White
Mounting Options: Raceway – painted satin SW 6378 Crisp Linen.
Face: 7328 white plex w/ Arlon 2500-253 Cardinal red vinyl applied as per artwork.
Trim: 3/4” white
Return: 5” welded painted white
LED: White
Mounting Options: Raceway – painted White
Face: 7328 white plex / Bio – Arlon 2500-253 Cardinal Red vinyl applied leaving white outline / Kinetics – Arlon 2500-2870 Blue vinyl applied leaving white outline / Capsule – Arlon 2500-2870 Blue vinyl applied as per artwork.
Trim: 1” black
Return: 4” pre-finished & welded – black
LED: White
Mounting Options: Raceway -painted SW 6379 Jersey Cream.
Face: Letters – 7328 white plex w// Arlon 2500-57 Olympic Blue vinyl as per artwork / Logos – 2447 white plex w/ Arlon 5590-122 Black perforated vinyl applied as per artwork / Capsule – 7328 white plex w/ Arlon 2500-22 Black & Arlon 2500-83 Regal red vinyl applied as per artwork.
Trim: Letters & Logos – 3/4” black Capsule – 1” black
Return: 4” pre-finished black
LED: White
Mounting Options: Raceway
Aluminum Face: .125 aluminum painted mate black and PMS 7506 C Beige as per artwork.
Face: 511 – 7328 white plex w/ Arlon 2500-22 black vinyl applied as per artwork.
Trim: 511 – 3/4” painted matte black.
Return: cabinet – 12” welded painted matte black / Interiors painted white.
Return: 511 – 4” welded painted matte black / Interiors painted white.
Illumination: 511 – Principal QwikMod White PLQM2-TW150-P / cabinet – includes 11S14 Bulbs & Sockets.
Face: 7328 White; Letters – 2500-76 Holly Green
Trim: 3/4″ Polished Gold
Return: 4″ Pre-finished Black
Mounting Options: Raceway
Face: 2447 White with digital print
Trim: 1″ Dark Blue
Return: 4″ pre-finished painted to match Dark Blue trim
Mounting Options: Raceway
Alum. Face: Cabinet – .125 routed aluminum painted satin PMS 7730 C Green and black
Plex Faces: Jack’s – 7328 white 3/4” plex w/ 1/2” push thru / Recreational Cannabis – white flat cut polycarbonate
Return: Cabinet – 18” welded painted satin black
Mounting Options: Self-Contained
Alum. Face: .090 aluminum; top section, bottom legs – painted to match satin SW 6256 Serious gray; middle section – painted to match satin SW 6523 Denim; bottom section – painted to match satin BM HC-41 Richmond Gold; 254 Essex street – 2500-20 white; ®, small YMCA – BR 120 Brushed Aluminum; bay state physical therapy – 2500-69 duronodic
Alum Trim: Tim not required
Return: top section – 10” welded painted to match satin SW 6256 Serious gray; middle section – 14” welded painted to match satin SW 6523 Denim; bottom section – 10” painted to match satin BM HC-41 Richmond Gold
Mounting Options: Self-Contained
Face: 2500-22 black and 2500-26 green
Alum Trim: 1″ x 1″ painted satin white
Return: 16” welded painted satin black
Mounting Options: Self-Contained
Face: 2447 white plex / VERACRUZ – Arlon 2500-143 poppy red and 2500-1090 yellow; MEXICAN RESTAURANT – 2500-143 poppy red, 2500-22 black, and 2500-1090 yellow; TRES – 2500-143 poppy red; 3 – 2500-1090 yellow; logos – digital print
Return: Letters, logo – 4” prefinished black
Return: cabinet – 18” welded painted satin black
Trim: VERACRUZ,TRES, 3 – 3/4” black / MEXICAN RESTAURANT, logos – 1” black
Mounting Options: Self-Contained
Face: .125 routed aluminum with digital print; HUDSON VALLEY • NY, ANGRY ORCHARRD, HARD CIDER – 3/4″ 7328 White acrylic w 1/2″ push thru with Arlon 2500-2283 Red; 3/4″ 7328 White acrylic with 1/2″ push thru
Reutrn: 18″ welded unpainted
Trim: Trim not required
Mounting Options: Self-Contained
Alum. Face: .125 routed aluminum painted PMS 7458 C Topaz Blue, PMS 2154 C Classic Blue and White; 415 West Main painted White
Plex Face: Logo – 3/4″ white acrylic with 1/2″ push thru with digital print to match PMS 7458 C Topaz Blue, PMS 7703 C Horizon Blue, PMS 3454 Cendre Blue and PMS 2154 C Classic Blue; Amberwell, HIGHLAND CLINIC – 3/4″ White acrylic with 1/2″ push thru with digital print to match PMS 2154 C Classic Blue
Trim: Trim not required
Return Depth: 11″ welded **painted three colors** PMS 7458 C Topaz Blue, PMS 2154 C Classic Blue, and White
Mounting Options: Self-Contained
Face: .125 Aluminum painted PMS 7699 C Blue & PMS 718 C Beige
Trim: Trim not required
Return Depth: 5″ welded painted PMS 7699 C Blue
Mounting Options: Blade
Face: Cabinet – routed aluminum painted two colors – Matthews MP 10252 Campbells Soup Red & Black backed with 7328-White with 2500-253 Cardinal Red, 2500-22 Black and die cut digital print; Letters – 7328 White
Trim: Letters – 3/4″ Black
Return Depth: Letters – 3″ pre-finished Black; Cabinet 12″ welded painted two colors Matthews MP 10252 Campbells Soup Red & Black;
Side Accents – 5.86″ welded painted two colors SW 6684 Brittlebrush & Black
Mounting Options: Self-Contained
Alum. Face: .125 aluminum painted to match PMS 484C roasted Red and PMS 4625 C Adobo Brown
Plex Face: Letters, dot, and center logo – clear 3/4″ push thru acrylic with digital print to match PMS 4625 C Adobo Brown and 2500-20 White
Trim: Trim not required
Return Depth: 5.5″ welded painted PMS 484 C Roasted Red
Mounting Options: Self-Contained
Alum. Face: Orange – Reverse channel painted to match 2500-44 Orange; theory – reverse channel painted to match 2500-33 Red; FITNESS – reverse channel painted to match 3M 3630-71 Shadow Gray
Return Depth: Orange – 3″ welded painted to match 2500-44 Orange; theory – 3″ welded painted to match 2500-33 Red; FITNESS – 3″ welded painted to match 3M 3630-71 Shadow Gray
Mounting Options: Wireway/Remote
Flat Cut Outs: To have inset .125 aluminum backs with RAIDER (inset backs) – digital print to match PMS 186C Red & White; Arrow (inset backs) – digital print to match Black & White
Face: No faces
Trim: Trim not required
Return Depth: RAIDER – 5″ welded painted PMS 186C Red; ** interior painted PMS 186C Red**; Arrow – 5″ welded painted Black; ** interior painted Black*
Illumination: Yellow LED 11 S14 Bulbs and Sockets
Mounting Options: Remote
Face: 7328 White with digital print to match PMS 535 C Blue, PMS 5395 C Dark Blue & PMS 2995 C Light Blue
Trim: 2.5″ x 2.5″ aluminum trim painted White
Return Depth: 8″ welded painted PMS 5395 C Dark Blue
Mounting Options: Cabinet/Self-Contained
Alum. Face: .125 aluminum painted Black, White and Cool Gray 9 C
Plex Faces: TALAMORE SQUARE, TS logo – 7328 White 3/4″ push thru acrylic; TALAMORE – 5590-122 Black perforated vinyl
Trim: Trim not required
Return Depth: 8″ welded painted Satin Black; TALAMORE – White
Mounting Options: Self-Contained
Face: Reverse Channel painted Satin MP 48103SP Brass Alloy
Return Depth: 2″welded painted Satin MP 48103SP Brass Alloy
Mounting Options: Remote
Face: 7328 White; Frost, Cake – 3M 3630-157 Sultan Blue; Your – 3M 3630-136 Lime Green; Cupcake – 3M 3630-227 Azure & 3M 3630-236 Turquoise
Trim: Frost, Cake – 1″ Dark Blue; Your – 1″ Holiday Green; Cupcake – 3/4″ Teal
Return Depth: 3″ welded painted Satin White
Mounting Options: Raceway
Alum. Face: .125 routed aluminum painted Matte Black
Plex Faces: White polycarbonate backing with digital print
Trim: Trim not required
Return Depth: 6″ welded painted Matte Black
Mounting Options: Self-Contained
Alum. Face: Routed .125 aluminum painted to match SW 6229 Tempe Star
Face: White polycarbonate
Trim: Trim not required
Return Depth: 14″ welded .080 returns painted to match SW 6229 Tempe Star
Mounting Options: Self-Contained
Alum. Face: CHILDREN’S ORCHARD ACADEMY, Tree, leaves – reverse channel painted Black; Circles – reverse channel painted PMS 2423C Light Green; Rings – reverse channel painted PMS 355C Green
Trim: Trim not required
Return Depth: CHILDREN’S, ACADEMY, Tree – 1.5″ welded painted Black; ORCHARD, leaves (inner ) – 3″ welded painted Black ; Leaves (outer 11) – 1.5″ welded painted Black; Circles – 1.5″ welded painted PMS 255C Light Green; Rings – 3″ welded painted PMS 355C Green
Mounting Options: Self-Contained
Face: 2447 White with digital print
Alum. Trim: Custom 1″ painted Black
Return Depth: 6″ painted Black
Mounting Options: Self-Contained
Face: Reverse Channel painted Matthews MP 46253SP Copper Metallic
Return Depth: 3″welded painted Matthews MP 46253SP Copper Metallic
Mounting Options: Remote
Face: Alum. Faces: Letters – Reverse Channel painted Satin Brushed Aluminum
Trim: Trim not required
Return Depth: 3″ welded Satin Brushed Aluminum
Mounting Options: Remote/Wireway
Face: Alum. Faces: Reverse Channel painted 2nd, swoosh, roof, window border – PMS 659 C Blue; ADULT MEDICAL DAY CAE – PMS 2165C Blue Gray; HOME – PMS 207 C Red and White; window panes – PMS 1205 C Yellow
Trim: Trim not required
Return Depth: 3″ welded painted swoosh, roof, window – PMS 659 C Blue; ADULT MEDICAL DAY CARE – PMS 2165 C Blue Gray; HOME – PMS 207 C Red
Mounting Options: Cabinet
Face: Reverse Channel painted white
Trim: Trim not required
Return Depth: 3″ painted PMS 154C copper (metallic)
Mounting Options: Radius Raceway
Face: Aluminum Faces: theo yianni’s & Swoosh – Reverse channel painted black. Plex Faces: Logo – 2447 white plex w/ digital print applied as per artwork
Trim: 3/4″ black
Return Depth: theo yianni’s & Swoosh – 3″ painted black / Interiors painted white / Logo – 3″ pre-finished black / Interiors white.
Mounting Options: Cabinet Mounted
Face: Reverse channel painted RAL 8007 Brown
Trim: Logo – Trim not required
Return Depth: 3″ painted RAL 8007 Brown with RGB LEDs
Mounting Options: Wireway Mounted
Face: Plex Face: logo – 2447 white plex w/ (phoenix) 2500-44 Orange vinyl overlay / (accents) 2500-15 Yellow vinyl overlay; Aluminum Faces: Reverse Channel – Phenix painted Matthews Brushed Aluminum
Trim: Logo – (Phoenix) – 3/4″ painted to match PMS 021C Orange / (Accents) 3/4″ painted to match PMS 122C Yellow
Return Depth: PHENIX – 5″ painted Matthews Brushed Aluminum / Logo – (phoenix) – 5″ painted to match PMS 021C Orange / (accents) 5″ painted to match PMS 122C Yellow
Mounting Options: Remote Mounted
Face: ATC & Swoosh – Reverse Channel, Broadband – 3/4″ 7328 white plex (1/2″ push thru) w/broad – arlon -67 bright blue vinyl / band – arlon 2500-106 briliant green vinyl
Trim: Trim not required
Return Depth: ATC – 3″ painted to match arlon 2500-106 brilliant green vinyl / swoosh – 3″ painted to match arlon 2500-67 bright blue vinyl
Mounting Options: Custom Shaped Raceway
Face: Reverse Channel
Trim: No Trim
Return Depth: Letters – 3″ painted white
Mounting Options: Bacer/Raceway Mounted
Face: Vict ry Sign – reverse channel / logo – 7328 white plex w/ digital print applied
Trim: Logo – ¾” black.
Return Depth: Vict ry Sign – 3.5″ painted PMS 286C blue / logo – 5″ painted PMS 286C blue
Mounting Options: Backer Panel & Raceway
Face: Reverse Channel
Trim: No Trim
Return Depth: 3″ Painted Black
Mounting Options: Raceway
Face: CABINET – Matthews Brushed Aluminum, SMASH – Reverse Channel, KITCHEN & BATH – 7238 White w/2500-22
Trim: No Trim
Return Depth: CABINET – 4″ painted Matthews brushed aluminum / SMASH – 3″ painted black
Mounting Options: Cabinet
Face: Aluminum Faces: Reverse Channel w/ haker – painted black / c – painted to match orange/ bar – painted Matthews med silver / capsule – routed out painted black & painted to match orange
Plex Faces: capsule – 7328 white acrylic w/ 1/2″ push thru
Trim: Trim not required
Return Depth: haker – 3″painted black / c – 4″ painted to match orange sample provided / bar – 4″ painted Matthews med silver / capsule – 2″ painted black & painted to match orange sample provided
Mounting Options: Non-Illuminated – Cabinet
Face: Welded Reverse Channel painted Dark Bronze
Trim: Trim not required
Return Depth: 3″ painted Dark Bronze
Mounting Options: Remote
Alum. Face: .125 route aluminum painted Matthews Medium Silver
Face: 3/4″ clear acrylic with 1/2″ push thru with TCBY – 3M 3630-118 Intense Magenta; Frozen Yogurt – 3M 3635-91 Smoke Gray (Day/Night vinyl)
Trim: Trim not required
Return Depth: 5″ Painted Matthews Medium Silver
Mounting Options: Self-Contained Cabinet
Face: 2447 White with digital print
Trim: 1″ Black
Return Depth: 4″ pre-finished Black
Mounting Options: Self-Contained
Face: .125 routed aluminum face painted MAP Satin Black backed with 7328 white plex / Plex to have arlon 2500-2510 red & arlon 2500-022 black vinyl applied as per artwork
Trim: Trim not required
Return Depth: 12″ painted MAP satin black
Mounting Options: Self-Contained
Face: Aluminum Faces: Cabinet (round) – routed aluminum with digital print applied as per artwork / Cabinet (bottom) – aluminum painted PMS 429C Gray (suede finish) / Welcome – reverse channel painted black. Plex Faces: Cabinet (round) – “isle of capri” 3/4″ 7328 white acrylic with 1/2″ push thru.
Trim: Trim not required
Return Depth: Return: Cabinet (round) – 18″ painted PMS 484C red / Interiors painted white / Cabinet (bottom) – 12″ painted PMS429C Gray (suede finish) / WELCOME – 3″ painted black / Interiors painted white.
Mounting Options: Cabinet – Self-Contained
Face: 7328 white plex w/2500-33 red, 2500-22 black, 2500-15 yellow, 2500-26 green vinyl applied with block out white vinyl applied in white areas
Trim: 3/4″ Green
Return Depth: 5″ pre-finished painted to match green trim
Mounting Options: Self-Contained
Face: Hammer Head & Logo – 7328 white plex w/digital print applied / Signs – 7328 white backer plex in wireway w/digital print applied / Phone# – 7328 white plex
Trim: 3/4″ Black
Return Depth: 4″ pre-finished black
Mounting Options: Custom Wireway mounted w/backer plex & LEDS – Self Contained
Face: 7328 White w/2500-2856 Purple & 2500-33 Red / Capsule – 2500-33 red
Trim: Letters & Logo – 3/4″ red / Capsule 1″ red
Return Depth: Letters & Logo – 5″ painted to match red coil / Capsule – 7.25″ painted to match red coil
Mounting Options: Square Tube Rails – Self-Contained
Face: 7328 White with apex & express – 2500-84 Tangerine/waterdrop & behind car – 2500-337 Process Blue
Trim: No Trim
Return Depth: Built in shoe box style / Flags – 4″ painted black / shield – 6″ painted black
Mounting Options: Self-Contained
Alum. Face: BEDROCK CONCRETE – painted Black
Plex Face: 2447 White with digital print to match PMS 287 C Blue
Trim: 1″ Dark Blue
Return Depth: BR Logo pieces – 4″ pre-finished painted MP 10147 Impulse Blue; BEDROCK CONCRETE – 3″ welded painted Black
Mounting Options: Remote
Alum. Faces: Cabinet – . 125 aluminum painted Matthews Mp55840 Cool Gray; Pan – reverse channel painted PMS 1795C Red
Plex Faces: Logos, letters – 7328 White; Logos – 2500-2051 Blue
Trim: logos – 3/4″ painted PMS 201C Blue; Letters – 3/4″ White
Return Depth: Pan – welded 1″ painted 1795C Red; Logos – 5″ painted PMS 201C Blue; Letters 5″ painted White
Mounting Options: Self-Contained Blade
Face: 7328 White; Face – 2500-22 Black; Back – 2500-106 Brilliant Green
Trim: 1″ Black
Return Depth: 4″ Black
Mounting Options: Wireway
Face: letters- 7328 White; Cabinet – Backed with 7328 White
Trim: 3/4″ Black
Return Depth: 5″ pre-finished Black
Mounting Options: Cabinet
Face: Letters – 2447 white with 5590-122 Black perforated overlay; Logo – 7328 White with 2500-22 Black
Trim: 3/4″ Black
Return Depth: 5″ pre-finished painted PMS 445 C Charcoal Gray
Mounting Options: Remote
Face: Shift! – 7328 White with 2500-22 Black and 2500-127 Intense Blue; Swooshes – 2447 White with 2500-127 Intense Blue
Trim: Shift! – 1″ Black; Swooshes – 1″ Intense Blue
Return Depth: Shift! – 4″ pre-finished Black; Swooshes – 4″ pre-finished Chevron Blue
Mounting Options: Raceway/Flat cut aluminum backer panel
Face: Letters, Capsule – 7328 White plex; Swoosh – 2447 White; Swoosh – 2500-106 Brilliant Green; Capsule – 2500-106 Brilliant Green
Trim: 1″ Black
Return Depth: 4″ Pre-Finished Black
Mounting Options: Remote
Face: 2447 white plex; RIVERSIDE, small logo – digital print to match PMS 285 C Medium Blue; Medical Group, large logo – digital print to match PMS 295 C Dark Blue
Trim: Riverside, Logos – 1″ White; Medical Group – 3/4″ White
Return Depth: Riverside, Logos – 1″ White; Medical Group – 3/4 White
Mounting Options: Remote
Face: Cat Head – reverse channel painted to match 3M 3630-121 Silver; Circle – Reverse channel painted White. Aluminum Faces: Cat Head – backed with 7328 White plex; Circle – 3/4″ 7328 White acrylic with 1/2″ push thru / Stitching – 2500-2283 Red; Cat Head – 2500-2856 Purple & 3M 3630-121 Silver
Trim: Trim not required
Return Depth: Cat head – 3″ painted to match 3M 3630-121 Silver; 3″ painted white
Mounting Options: Self-Contained
Face: 7328 white plex w/ digital print applied as per artwork.
Trim: 1″ Black
Return Depth: 4″ Pre-Finished Black
Mounting Options: Remote
Face: Condon – 2793 Red plex / Signs – 2447 White plex with arlon 2500-22 Black vinyl overlay
Trim: 3/4″ Black
Return Depth: 5″ Pre-finished Black
Mounting Options: Custom Raceway
Face: pepper, I – 2793 red plex / S- 2119 orange plex / P, E – 2016 yellow plex w/diffuser film applied / C – 2037 yellow plex / stem – 2108 green plex; Flat cut-outs – letters mounted: .090 flat cut aluminum backer painted black
Trim: 3/4″ Black
Return Depth: 5″ Pre-finished Black
Mounting Options: Raceway Mounted
Face: Ted’s – 7328 White w/2500-33 red vinyl applied as outline / Coney Island – 2037 Yellow plex. Backer Panel – .125 Flat Cut Aluminum painted SW 6321 Red Bay.
Trim: 1″ Black
Return Depth: 5″ Pre-finished Black
Mounting Options: Backer Panel & Raceway Mounted
Face: 2447 white plex w/digital print applied to all – yellow to match 8500-021 yellow
Trim: 3/4″ Black
Return Depth: 5″ Pre-Finished Black
Mounting Options: Wireway
Face: Aluminum Face: routed aluminum painted (two colors) Matthews Proseco 48101SP Gold Standard & PMS 7497C Green as per artwork Plex Face: 3/4″ 7328 white acrylic with 1/2″ push thru
Trim: Trim not required
Return Depth: Return: 8″ painted Matthews Proseco 48101SP Gold Standard / Interiors painted white.
Mounting Options: Blade Mounted
Face: 7328 White plex w/digital print applied to both sides
Trim: 1″ Black
Return Depth: 8″ Painted Black
Mounting Options: D/F Blade Sign
Face: Flat Cut-outs: ZerOday – 1.25 flat cut aluminum painted black; Aluminum Face: .125 routed alumnium faces painted brushed aluminum & black per artwork; Plex Face: Backed with clear lexan; Digital Print applied as per artwork/Brewing Co. portion to be applied to face of cabinet / Bricks to match PMS 7417C Orange
Trim: Trim not required
Return Depth: 5″ painted brushed aluminum
Mounting Options: Blade Mounting
Alum. Face: Cabinet – .125 routed aluminum painted satin Black and White
Plex Face: Legacy logo – 7328 White; Legacy – 2500-33 Red; Feather logo – 7328 White 3/4″ plex with 1/2″ push thru and 250–22 Black and 2500-33 Red; SPORTS BAR & GRILL – 7328 White with 2500-22 Black and 2500-33 Red
Trim: Legacy logo – 1″ White; SPORTS BAR & GRILL – 3/4″ White
Return Depth: Cabinet – 6″ welded painted Satin Black; Legacy – 4″ welded painted Satin Black; SPORTS BAR & GRILL – 4″ pre-finished Black
Mounting Options: Self-Contained
Face: White polycarbonate with digital print to match PMS Reflex Blue U, PMS 173 U Orange, and White
Alum. Trim: 2″ x 2″ painted Satin Black
Return Depth: 6″ welded painted Satin Black
Mounting Options: self-Contained
Face: 2447 White with digital print
Trim: 1″ Black
Return Depth: 4″ pre-finished Black
Mounting Options: Raceway
Plex Faces: Jersey Mike’s – 7328 White
Alum. Faces: Wireway – Reverse Channel painted Satin ***Three Colors*** PMS 485 C, PMS 534 C Blue, and White (Suede)
Trim: Jersey Mike’s – 3/4″ painted satin mP 41342 SP Brushed Aluminum
Return Depth: Jersey Mike’s – 3′ pre-finished painted satin MP 41342 SP Brushed Aluminum; Wireway – 2″ welded painted Satin **three colors** PMS 485C, PMS 534 C Blue and White (suede finish)
Mounting Options: Remote/Wireway
Alum. Face: Cabient top and Bottom – Painted Black and 2500-253 Cardinal Red & 5570-120 White; Cabinet middle – painted Matthews MP 28448 Umbra Grey Metallic (satin) and Brushed Aluminum
Plex: Letters – 7328 White 2500-253 Cardinal Red; Cabinet (bottom) – 7328 White Push Thru
Trim: 1″ White
Return Depth: 4″ White
Mounting Options: Cabinet
Face: Letters & Logo – 7328 White painted Black
Trim: Trim not required
Return Depth: 2″ welded painted White
Mounting Options: Backer Panel/Cabinet
Face: Cabinet (top), Cabinet (bottom) – .125 aluminum painted PMS 4675C Tan / Cabinet (middle) – .125 aluminum painted Black
Trim: Trim not required
Return Depth: Cabinet (top), cabinet (bottom) – 7″ welded painted PMS 4675C Tan; Cabinet (middle) – 10″ welded painted Black
Mounting Options: Cabinet
Face: Aluminum Faces: Top (finn) & Bottom – painted PMS 285 C blue / Middle – painted PMS 369 C green, 285 C blue, PMS 284 C light blue & white as per artwork / Reveal – painted PMS 369 C green.
Trim: Trim not required
Return Depth: Top (finn) – 7.25″ painted PMS 285 C blue / Middle – 11″ painted white / Reveal – 7.25″ painted PMS 369 C green / Bottom – 11″ painted PMS 285 C blue.
Mounting Options: Pole Well Mounted
Alum. Face: .125 routed out aluminum painted White and PMS 2133 C Blue
Plex Face: Logo – 1/2″ 7328 White push thru plex with 2500-157 Sultan Blue vinyl; “Nationwide is on your side” – 1/2″ push thru plex with 2500-22 Black ; “Clark Group – Adam Smith, Agent” – 1/2″ White push thru; ® – 2500-22 Black
Trim: Trim not required
Return Depth: 5″ painted White & PMS 2133 C Blue
Mounting Options: Self-Contained
Alum. Faces: Letters – reverse channel painted White; Cabinet – aluminum painted (four colors) PMS Reflex Blue U, PMS 1-2U Yellow, Black & White (Suede Finish)
Trim: Trim not required
Return Depth: Letters – 3″ painted White; Cabinet – 2″ square tube painted PMS Reflex Blue (suede finish)
Mounting Options: Cabinet/Remote
Face: 7328 white polycarbonate w/ arlon 2500-33 red, 2500-36 dark blue & 2500-22 black vinyl
Trim: 1″ x 1″ aluminum trim painted white
Return Depth: 6″ painted black
Mounting Options: Self-Contained
Face: 7328 White with 2500-33 Red & 2500-22 Black
Trim: 2″ x 2″ aluminum painted Black
Return Depth: 12″ painted Satin Black
Mounting Options: Self-Contained
Face: 7328 White with digital print
Alum. Trim: 1″ painted White
Return Depth: 8″ welded painted White
Mounting Options: Self-Contained
Face: 2447 White with Oracal 8500-25 Brimstone Yellow and Arlon 2500-22 Black
Trim: 1″ Black
Return Depth:CALIFORNIA – 6″ welded painted Satin Black; THE, Way – 3″ pre-Finished Black
Mounting Options: Raceway
Face: 7328 White with 2500-131 Gold Metallic, 2500-121 Silver Metallic & 2500-22 Black
Trim: 1″ Black
Return Depth: 5″ painted Black
Mounting Options: Remote
Face: 2447 White with digital print
Trim: 1″ Black
Return Depth: 4″ pre-finished Black
Mounting Options: Remote
Face: 2447 White with digital print
Trim: 1″ Black
Return Depth: 4″ Pre-Finished Black
Mounting Options: Raceway
Face: 7328 White; WINGS, THINGS – 2500-22 Black and 2500-33 Red; Logo – 2500-22 Black and 2500-33 Red; Capsule – 2500-22 Black, 2500-25 Sunflower and 2500-33 Red
Trim: 1″ Black
Return Depth: 4″ pre-finished Black
Mounting Options: Raceway
Face: 2447 White; Logo – digital print to match C:0. M:55,Y:2, K:0; Pink – C: 14, M: 98, Y:0, K:0; Pink & Black; Contour Channel Letters – digital print to match C:14, M:98, Y:0, K:0 Pink & black
Trim: 1″ black
Return Depth: 5″ pre-finished Black
Mounting Options: Raceway
Face: 7328 White with bedding – 2500-157 Sultan Blue as border & 2500-73 Red
Trim: 3/4″ painted to match PMS 288C Blue
Return Depth: 5″ painted to match PMS 288C Blue
Mounting Options: Remote
Face: 7328 White with 2500-26 Dark Blue and 2500-2930 Blue
Trim: 1″ White
Return Depth: 4″ pre-finished White
Mounting Options: Remote
Face: 7328 White with 2500-44 Orange and 2500-106 Brilliant Green
Trim: 1″ Black
Return Depth: 4″ pre-finished Black
Mounting Options: Raceway
Face: 7328 White; 2500-33 Red
Trim: 1″ White
Return Depth: 4″ pre-finished White
Mounting Options: Raceway
Face: 7328 White Plex with 2500-22 Black & 2500-307 Dark Aqua vinyl applied.
Trim: 1″ Black
Return Depth: 5″ Painted Black
Mounting Options: Self-Contained
Face: 7328 White with digital print
Trim: 1″ Black
Return Depth: 4″ pre-finished Black
Mounting Options: Remote
Face: 7328 White with Micheli’s – 2500-59 Dark Brown & 2500-25 Sunflower Yellow; Capsule – 2500-112 olive Green, 2500-59 Dark Brown & 2500-25 Sunflower Yellow
Trim: Micheli’s – 3/4″ White; Capsule – 3/4″ Brown
Return Depth: Micheli’s – 5″ pre-finished White; Capsule – 5″ pre-finished Brown
Mounting Options: Raceway
Face: Mr. Mikes – 7328 White plex with 2500-33 Red & 2500-22 Black; Capsule – 7328 White with 2500-22 Black
Trim: 1″ Black
Return Depth: 5″ pre-finished Black
Mounting Options: Remote
Face: 7328 White with 2500-133 Raspberry & 2500-22 Black
Trim: 1″ Gold
Return Depth: 5″ pre-finished Black
Mounting Options: Self-Contained
Face: 2447 White with 2500-44 Orange & 2500-22 Black
Trim: 1″ Black
Return Depth: 5″ painted Black
Mounting Options: Raceway
Face: 7328 White with 2500-33 Red
Trim: 1″ x 1″ aluminum trim painted to match Red Jewelite trim
Return Depth: 5″ painted to match red Jewelite trim
Mounting Options: Self-Contained
Face: Logo – 2447 White with digital print; Contour Channel, Capsule – 7328 White with Contour Channel – 2500-33 Red; Capsule – 2500-22 Black
Trim: 1″ Black
Return Depth: 5″ pre-finished Black
Mounting Options: Raceway
Face: TBD
Trim: TBD
Return Depth: TBD
Mounting Options: TBD
Face: 7328 White with 2500-253 Cardinal Red
Trim: 1″ Black
Return Depth: 8.5″ Welded painted Satin Black
Mounting Options: TBD
Face: 2447 White with digital print
Trim: 3/4″ Brown
Return Depth: 5″ pre-finished Autumn Brown
Mounting Options: Remote
Face: 7328 White with 2500-22 Black
Trim: 1″ Black
Return Depth: 4″ welded painted Black
Mounting Options: Raceway
Face: 7328 White with Arlon 2500-22 Black and Oracal 8800-17 Cherry Red
Trim: 1″ Black
Return Depth: 4″ pre-finished Black
Mounting Options: Raceway
Face: 2447 White with digital print applied
Trim : 1″ Black
Return Depth : 4″ Pre-Finished Black
Mounting Options : Remote
Face: 2447 White with digital print
Trim: 1″ Black
Return Depth: 4″ pre-finished Black
Mounting Options: Raceway
Face: 7328 White with digital print to match PMS 7549 C, 109 C, Black and White
Trim: 1″ Black
Return Depth: 4″ pre-finished Black
Mounting Options: Remote
Alum. Face: .125 route aluminum painted Brushed Aluminum and Black
Plex. Face: SIGN PRO logo, Perfect to the Letter – 7328 White with 3/4″ push thru plex with 2500-22 Black outline and 2500-15 Yellow
Trim: Trim not required
Return Depth: 16″ welded painted Satin Black
Mounting Options: Self-Contained
Face: 7328 White with digital print
Trim: 1″ Black
Return Depth: 4″ pre-finished Black
Mounting Options: Remote
Face: 7328 White with 2500-22 Black and 2500-33 Red
Trim: 1″ Black
Return Depth: 5″ pre-finished Black
Mounting Options: Self-Contained
Face: 2447 White with digital print
Trim: 1″ Black
Return Depth: 4″ pre-finished Black
Mounting Options: Remote
Face: 7328 White with 2500-36 Dark Blue and 2500-337 Process Blue
Trim: 1″ White
Return Depth: 5″ Painted White
Mounting Options: Raceway
Face: 2447 White; BIG STEEL, Box (border) – 5590-122 Black perforated vinyl; G – 2500-2940 Blue
Trim: 3/4″ Black
Return Depth: 5″ pre-finished Black
Mounting Options: Wireway
Face: 2447 White with digital print
Trim: 1″ Black
Return Depth: 4″ pre-finished Black
Mounting Options: Remote
Face: 7328 White with 2500-44 Orange & 2500-22 Black
Trim : 1″ Black
Return Depth : 4″ pre-finished Black
Mounting Options : Remote
Face: 7328 White with 2500-22 Black, 2500-33 Red, 2500-25 Sunflower and 2500-2051 Blue
Trim : 1 “Black
Return Depth : 5” pre-finished Black
Mounting Options : Self-Contained
Face: 7328 White with 2500-57 Olympic Blue & 2500-2856 Purple
Trim: 1″ Black
Return Depth: 5″ pre-finished White
Mounting Options: Raceway
Face: 2447 White with digital print to match PMS 293 C Blue, PMS 2293 C Green, and PMS 485 C Red
Trim: 1″ White
Return Depth: 4″ pre-finished White
Mounting Options: Raceway
Face: 2447 White with digital print
Trim : 1″ black
Return Depth : 4″ Pre-Finished Black
Mounting Options : Remote
Face : 2447 white / Digital Print applied as per artwork
Trim : 1″ Black
Return Depth : 5″ Pre-Finished Black
Mounting Options : Self-Contained
Face: 7328 White plex with 2500-25 Sunflower, 2500-44 Orange, 2500-156 Vivid Green, 2500-157 Sultan Blue, 2500-57 Process Blue, 2500-51 Silver Grey, and 2500-22 Black vinyl applied as per art.
Trim: 3/4″ Black
Return Depth: 5″ Pre-Finished Black
Mounting Options: Remote
Face: Digital Print
Trim: 1″ Bronze
Return Depth: 1″ Painted Bronze
Mounting Options: Remote
Face: Channel border 2447 w/2500-127 Intense Blue vinyl on channel border
Trim: 3/4″ Intense Blue on channel border
Return Depth: (Welded) 4″ return painted to match intense blue trim / aluminum inset panel painted white / inset panel mounted 3″ away from back of can (Channel border will project 1″ past white inset panel)
Mounting Options: Channel border, reverse channel box, reverse channel letters – lighted
Face: Arlon 2500-33 red & 2500-22 Black vinyl
Trim: 1″ White
Return Depth: Black
Mounting Options: Raceway Mounted
Face: 2447 white plex w/ arlon 2500-525 bright yellow vinyl overlay.
Trim: 3/4″ Black
Return Depth: 5″ Painted Black
Mounting Options: Raceway
Face:7328 White with 2500-125 Golden Yellow and 2500-97 Bristol Blue
Trim: 1″ Black
Return Depth: 5″ Black
Mounting Options: Self-Contained
Face: .125 flat cut aluminum painted Black w/ digital print applied as per artwork (Backs painted black)
Trim: Trim not required
Return Depth: No Return
Mounting Options: Square Tube Rails painted black
Face: 7328 White with 2500-44 Orange & 2500-22 Black
Trim: 1″ Black
Return Depth: 4″ Black
Mounting Options: Self-Contained
Face: 2447 White with 2500-106 Brilliant Green
Trim: 1″ Black
Return Depth: 4″ Black
Mounting Options: Remote
Face: 7328 White with 2500-97 Bristol Blue
Trim: 1″ Dark Blue
Return Depth: 4″ Painted to match Dark Blue
Mounting Options: Raceway
Face: Fty Rooy -7328 White with 2500-127 Intense Blue overlay; logo t- 7328 White with 2500-127 Intense Blue, 2500-22 Black, and 2500-106 Brilliant Green; Logo feet – 2447 White with 2500-15 Yellow and 2500-33 Red; Capsule – 7328 White with 2500-106 Brilliant Green
Trim: Fty Rooy, Logo T, Logo feet – 2/4″ Black; Capsule 1″ Black
Return Depth: 4″ Black
Mounting Options: Raceway
Face: 2447 White with 2500-2856 Purple and 2500-22 Black
Trim: 2/4″ Black
Return Depth: 4″ Black
Mounting Options: Raceway
Face: Nails, O Logo, ass – 7328 White; tree logo – 2447 white with digital print; ass – 3M 3630-36 Dark Blue; Nails, O logo – 3M 3630-33 Red
Trim: 3/4″ Black
Return Depth: 4″ White
Mounting Options: Raceway
Face: A(#1), D – 2441 Blue; MERIC, A (#2), ‘S, KI, S – 2793 Red; Capsule – Backed with 7328 White
Alum. Face: Capsule – Routed aluminum painted to match blue trim
Trim: A (#1), D – 3/4″ Blue; MERIC, A (#2), ‘S, KI, S – 3/4″ Red
Return Depth: 5″ Painted White
Mounting Options: Self-Contained
Face: 2447 White with digital print
Trim: COSTA – 3/4″ Black; AZ, logo – 1″ Black
Return Depth: 4″ Black
Mounting Options: Raceway
Face: 7328 White Plex w/ letters – arlon 2500-57 Olympic Blue Vinyl applied leaving white outline / Logos – digital print applied as per artwork
Trim: 1″ Black
Return Depth: 5″ Pre-Finished Black
Mounting Options: Raceway Mounted
Face: 7328 White plex with Bead – Arlon 2500-307 Dark Aqua / Harbor – Arlon 2500-71 Shadow Gray vinyl / Logo – Arlon 2500-51 Silver Gray & 2500-71 Shadow Gray vinyl leaving white outline on all
Trim: 3/4″ Black
Return Depth: 5″ Pre-Finished Black
Mounting Options: Raceway
Face: 2447 White plex with letters – arlon 2500-22 Black vinyl / Logo – Digital print applied.
Trim: 3/4″ Brushed Chrome
Return Depth: 5″ Pre-Finished Bright Brushed Clear (Special coil).
Mounting Options: Raceway
Face: Lorenzo’s – 2108 Green plex / Pizza – 2793 Red plex
Trim: Lorenzo’s – 3/4″ Green / Pizza – 3/4″ Red
Return Depth: Lorenzo’s – 5″ pre-finished painted to match green trim / Pizza – 5″ prefinished Red
Mounting Options: Raceway Mounted
Face: 2447 White w/2500-106 Brilliant Green vinyl applied
Trim: 1″ Black
Return Depth: 5″ Pre-Finished Black
Mounting Options: Custom Raceway Mounted
Face: 2447 white plex with digital prints applied
Trim: 1″ Black
Return Depth: 4″ pre-finished Black
Mounting Options: Raceway
Face: LOGO – 7328 white w/ arlon 2500-33 red & 2500-2051 blue vinyl / LETTERS – 2447 white w/ arlon 2500-2051 blue vinyl
Trim: 3/4″ White
Return Depth: 5″ pre-finished White
Mounting Options: Raceway with Backer Panel
Face: LETTERS – 7328 white plex w/ 2500-22 black vinyl outline applied / OVAL – clear plex w/ 2500-22 black & 2500-25 sunflower yellow vinyl applied to second surface
Trim: LETTERS – 3/4″ black / OVAL – 1″ black
Return Depth: 5″ pre-finished black
Mounting Options: Custom Raceway
Face: LETTERS – 7328 white w/ digital print / CAPSULE – 7328 white w/ 2500-22 black
Trim: 3/4″ Black
Return Depth: 5″ Pre-Finished Black
Mounting Options: Raceway
Face: 2447 white plex w/ digital prints PMS 641c blue, white, black & PMS 443c gray
Trim: 3/4″ Black
Return Depth: 5″ pre-finished White
Mounting Options: Raceway
Face: SMOKE SHOP – 2037 Yellow; 11 – 7328 White; Logo – Clear acrylic with digital print; Capsule – 7328 White with 2500-22 Black
Trim: SMOKE SHOP, 11, Logo – 3/4″ Black; Capsule – 1″ White
Return Depth: 4″ pre-finished Black
Mounting Options: Raceway
Alum. Face: Cabinet – routed aluminum painted PMS 2757C Blue
Plex Face: Cabinet – backed with 7328 White; Letters – 2447 White; Logos – 7328 White; Letters – 5590-122 Black perforated vinyl overlay; Logos – 2500-3238 European Blue
Trim: Letters – 3/4″ Black; Logo – 1″ Black
Return Depth: Cabinet – 10″ Painted PMS 2757C Blue; Letters – 5″ Painted Black; Logos – 5″ painted Black
Mounting Options: Cabinet
Face: Letters – 7328 White; Logos, Capsule – 2447 White with digital print
Trim: Letters, Logos (small) – 3/4″ Black; Logo (large), Capsule – 1″ Black
Return Depth: 4″ pre-finished Black
Mounting Options: Remote
Face: Letters – 2447 White with letters – 5590-122 Black perforated vinyl; Capsule – 2500-22 Black
Trim: 1″ Black
Return Depth: 5″ pre-finished Bronze
Mounting Options: Raceway
Face: 2447 White; Letters – 5590-122 Black Perforated vinyl; Logo – Digital Print
Trim: Letters – White; Logo – White
Return Depth: 4″ White
Mounting Options: Raceway
Face: Letters – 2447 with 2500-133 Raspberry vinyl; Capsule – 7328 White
Trim: Letters – 3/4″ White; Capsule – 1″ White
Return Depth: 5″ Pre-finished White; Capsule – 9″ painted White
Mounting Options: Self-Contained
Face: 2447 White with digital print
Trim: Letters – 3/4″ Red; Logo – 1″ Red
Return Depth: 4″ Pre-finished Hunter Red
Mounting Options: Remote
Face: Letters – 7328 White; Logo – 2447 White with digital print
Trim: Letters – 3/4″ Red; Logo – 1″ Red
Return Depth: 4″ pre-finished Black
Mounting Options: Remote
Face: 7328 White w/2500-2856 Purple & 2500-33 Red / Capsule – 2500-33 red
Trim: Letters & Logo – 3/4″ red / Capsule 1″ red
Return Depth: Letters & Logo – 5″ painted to match red coil / Capsule – 7.25″ painted to match red coil
Mounting Options: Square Tube Rails – Self-Contained
Face: 2114 Blue
Trim: 3/4″ Black
Return Depth: 4″ pre-finished Black
Mounting Options: Raceway
Face: 2793 Red
Trim: 3/4″ Red
Return Depth: 5″ pre-finished Black
Mounting Options: Raceway
Face: 7328 White with ta logo – 2500-143 Poppy Red & 2500-22 Black; ndy – 2500-143 Poppy Red; LEATHER, Bars (left) – 5590-122 Black Perforated vinyl overlay; Bar (right) – 5590-122 Black & 6670-120 White perforated vinyl
Trim: ta (logo) – 3/4″ Red & 3/4″ Black; ndy – 3/4″ Red; LEATHER – 3/4″ Back; Bars – 1″ Black
Return Depth: 5″ pre-finished Black
Mounting Options: Raceway
Face: 2447 White with digital print to match PMS 368 C Green
Trim: 1″ Black
Return Depth: 4″ pre-finished Black
Mounting Options: Raceway
Face: 7328 white w/LETTERS – 2500-127 Intense blue / LOGO – 2500-157 sultan blue, 2500-127 Intense blue & 2500-253 cardianl red
Trim: LETTERS – 3/4″ black / LOGO – 1″ black
Return Depth: LETTERS – 5″ pre-finished black / LOGO – 5″ painted
Mounting Options: Raceway
Face: 2447 White with 2500-253 Cardinal Red
Trim: 1″ White
Return Depth: 4″ pre-finished Black
Mounting Options: Remote
Face: Letters – 2793 Red; Logo – 7328 White with 2500-2510 Red, 2500-22 Blank, and 2500-51 Silver Gray
Trim: Letters – 3/4″ Black; Logo – 1″ Black
Return Depth: 4″ pre-finished Black
Mounting Options: Raceway
Face: 2447 White; WINE on NINE – 2500-87 Royal Blue; Bars – digital print to match PMS 528C Purple; 9 – digital print to match 2500-87 Royal Blue & PMS 528C Purple
Trim: WINE on NINE – 3/4″ Blue; Bars, 9 – 3/4″ White
Return Depth: WINE on NINE – 5″ Pre-finished Heron Blue; Bars, 9 – 5″ Pre-finished White
Mounting Options: Raceway
Face: 2447 White w/2500-246 Teal vinyl overlay
Trim: 1″ Teal
Return Depth: 5″ Pre-Finished painted to match teal trim
Mounting Options: Raceway Mounted
Face: Delici – 2447 White w/2500-78 vivid rose / Yoso – 2447 white w/2500-106 brilliant green / Capsule – 7328 White w/vivid rose
Trim: 3/4″ White
Return Depth: 5″ Pre-Finished White
Mounting Options: Raceway Mounted
Face: A ESS POINT – 2447 white plex w/ arlon 2500-2051 blue / X (left) & BAR – print to match PMS 7453c light blue / X (right) – print to match PMS 656c light blue
Trim: AXESS POINT – 3/4″ white / CAPSULE & BAR – 1″ black
Return Depth: LETTERS – 5″ pre-finished black / CAPSULE & BAR – 5″ painted black
Mounting Options: Raceway
Face: 2447 White with digital print to match 3M 3630-68 Rose Mauve
Trim: 3/4″ Black
Return Depth: 4″ pre-finished Black
Mounting Options: Raceway
Face: 2447 White with digital print
Trim: 1″ Black
Return Depth: 4″ pre-finished Black
Mounting Options: Raceway
Face: Letters – 2447 White with 2500-57 Olympic Blue; Capsule – routed aluminum painted Black with 3/4″ 7328 White with 1/2″ push thru copy
Trim: Letters – 1″ White
Return Depth: Letters 4″ pre-finished White; Capsule – 4″ welded painted Black
Mounting Options: Remote
Face: 2447 White; FLORAL & GIFTS – 5590-122 Black perforated vinyl; Bliss – digital print; Logo – digital print
Trim: Bliss, Logo – 1″ Black; FLORAL & GIFTS – 3/4″ Black
Return Depth: 5″ pre-finished Black
Mounting Options: Raceway
Face: 7328 White; PHO – 2500-44 Orange; Capsule – 2500-44 Orange
Trim: PHO & Capsule 1″ Orange; VIETNAM 1″ White
Return Depth: 5″ pre-finished Black
Mounting Options: Raceway
Face: 7328 White; Capsule – 2500-22 Black
Trim: Letters – 3/4″ Black; Capsul – 1″ Black
Return Depth: 4″ pre-finished Black
Mounting Options: Raceway
